| PRODUCT SPECIFICATIONS | |
|---|---|
| Socket: | LGA 1700 |
| Chipset: | Intel B760 |
| Form Factor: | Micro-ATX |
| Memory: | 4 x DDR5 DIMM slots, up to 192GB (Supports Dual Channel) |
| Expansion Slots: | 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x16 (x4 mode), 1 x PCIe 3.0 x1 |
| Storage: | 2 x M.2 (PCIe 4.0 x4), 4 x SATA 6Gb/s |
| LAN: | Intel 2.5GbE LAN |
| USB Ports: | 1 x USB 3.2 Gen 2×2 Type-C, 3 x USB 3.2 Gen 1, 2 x USB 2.0 (rear), plus internal headers |
| Audio: | Realtek ALC897 Codec, High-Definition Audio |
| Graphics Interface: | 1 x HDMI 2.0, 1 x DisplayPort 1.2 |
| BIOS: | Q-Flash Plus Support |
| Operating System: | Windows 11/10 (64-bit) |
| ITEM DIMENSIONS | |
| Height: | 244 mm |
| Length: | 244 mm |
| Width: | Micro-ATX Form Factor |
| Net Weight: | 1.2 kg |
| Color: | Black |
| WARRANTY INFORMATION | |
| Warranty: | 3 Years |
GIGABYTE B760M AORUS PRO M-ATX Motherboard – LGA1700 Intel B760 DDR5, Dual M.2, PCIe 4.0, USB 3.2 Gen 2×2, 2.5GbE LAN
The GIGABYTE B760M AORUS PRO M-ATX Motherboard is a high-performance Micro-ATX motherboard designed for Intel’s 12th and 13th, 14TH Gen Core processors with LGA1700 socket. It supports up to 192GB of cutting-edge DDR5 memory and features dual PCIe 4.0 x4 M.2 slots for ultra-fast storage. Its solid power design and advanced thermal solutions ensure maximum performance under load.
Integrated Intel 2.5GbE LAN offers fast and stable network connectivity, ideal for gamers and content creators. The board includes multiple USB 3.2 Gen 2 ports including a high-speed USB 3.2 Gen 2×2 Type-C for faster data transfers. HDMI 2.0 and DisplayPort 1.2 support high-resolution displays.
With Q-Flash Plus, BIOS updates are effortless without needing a CPU or memory installed. The Realtek ALC897 audio chipset delivers immersive sound quality for multimedia and gaming. Designed for flexibility, performance, and future-proofing, the GIGABYTE B760M AORUS PRO is a robust solution for any modern PC build.
